Vacuum Drying Oven

Vacuum Drying Oven Introduction: Vacuum Drying Box is widely used in biochemistry, chemical and pharmaceutical, health care, agricultural research, environment protection and other areas of research and application for powder drying, baking and all kinds of glass containers ' disinfection and...

Send Inquiry

Vacuum Drying Oven

Introduction:

Vacuum Drying Box is widely used in biochemistry, chemical and pharmaceutical, health care, agricultural research, environment protection and other areas of research and application for powder drying, baking and all kinds of glass containers '

disinfection and sterilization. Especially for those drying heat-sensitive, labile, oxidizing material and decompounded to carry on fast and effective drying process.

Feature:

1.The chamber is cuboid so as to maximize the volume. Microcomputer intelligent;temperature controller, makes temperature control accurate and reliable.

2.The working room uses ordinary sprayed steel plate or stainless steel plate, good cold-roll shelf sheets cover, with anti-static plastic coating. 3.Storage, heating, experiments and drying are all doing in the environment with no oxygen or filled with inert gas, so oxidation will not happen. 4.The tightness of the door can be adjusted by user optionally. Wholly-shaped silicone rubber door seal ensures the high vacuum degree in chamber.

Model	DZF6020	DZF6021	DZF6050	DZF6051
Volume	24L	24L	52L	52L
Liner size(mm)	300×300×275	300×300×275	415×345×370	415×345×370
Dimension(mm)	480×610×470	480×610×470	720×550×510	720×550×510
Supply voltage	AC 220V 50Hz
Temperature control range	RT+10~200℃
Temperature fluctuation	±1℃
Vacuum degree	≤133(Pa)
Heating power	500W	500W	1200W	1200W
Timing range	0-9999min
Internal material	Stainless steel	Cold rolled sheet	Stainless steel	Cold rolled sheet
